300*300*400 mm large building volume, available for big ideas.
4.3-inch full color high definition Capacitive touch screen. Friendly and easy to use UI with rich features.
TMC2208 motor drive system, effective denoising, printing without disturbance.
Matrix auto-leveling with high precision distance sensor and dynamic leveling compensation.
Enable to pause and change filaments with different colors in mid-print so as to print multi-color models.
Sensitive real-time filament run-out detecting system. Auto pause printing when filament runs out.
Power outage protection and printing recovery. One-key continue printing with no break.
LED auxiliary lighting, observe printing status more clearly at anytime.
One glance printing status light using full color LED. Customize your own printer light color.
MEAN WELL power supply, high efficiency, reliable and long life. Overall failure protection, safe to use.
Remove print nice and easy with the detachable magnetic print bed. No need of a scraper.
Using optoelectrical limit switch for positioning. High sensitivity, reliable and durable.
|Precision||X/Y: 0.05mm, Z: 0.1mm|
|Print Speed||Up to 150mm/s|
|Nozzle Travel Speed||Up to 200mm/s|
|Supported Materials||PLA, ABS, PETG|
|Nozzle Temperature||Up to 260℃|
|Heated Bed Temperature||Up to 100℃|
|Connectivity||USB, Micro SD Card|
|Display||4.3” Full Color Touch Screen|
|Language||English / Chinese|
|Printing Softwares||Cura, Rapetier-Host, Simplify 3D|
|Input File Formats||STL, OBJ, JPG|
|Output File Formats||GCODE, GCO|
|Support OS||Windows / Mac|
|Operating Input||100-120 VAC / 220-240 VAC 360W|
|Product Weight||22 kg|
|Product Dimensions||545*575*645 mm|
|Shipping Weight||16.8 kg|
|Package Dimensions||630*605*230 mm|
Q1. What’s the machine’s print size?
Q2. Does this machine support two-color printing?
A2: It’s a single nozzle structure, so it doesn’t support two-color printing.
Q3. What’s the printing accuracy of the machine?
A3: The standard configuration is a 0.4mm nozzle, which can support an accuracy range of 0.1-0.4mm
Q4. Does the machine support to use the 3mm filament?
A4: Only supports 1.75mm diameter filaments.
Q5. Which filaments support to print in the machine?
A5: It supports printing the PLA, PETG, ABS, TPU and other linear filaments.
Q6. Does the machine support to connect to a computer for printing?
A6: It supports online and offline to print, but it is suggested to print offline that will be better.
Q7. If the local voltage only 110V, does it support?
A7: There are 115V and 230V gears on the power supply for adjustment, DC: 24V
Q8. How is the power consumption of the machine?
A8: The overall rated power of the machine is 350W, and the power consumption is lower.
Q9. What’s the highest nozzle temperature?
A9: 250 degrees Celsius.
Q10. What is the maximum temperature of the hotbed?
A10: 100 degrees Celsius.
Q11. Does the machine have the function of continuous power off?
A11: Yes, it does.
Q12. Does the machine have a material breakage detection function?
A12: Yes, it does.
Q13. Is there a double Z-axis screw of the machine?
A13: No, it’s a single screw structure.
Q14. Are there any requirements for the computer system?
A14: Currently, it can be used in Windows XP/Vista/7/10/MAC/Linux.
Q15. What’s the printing speed of the machine?
A15: The best printing speed of the machine is 50-60mm/s.
